VES AIR CIRCULATOR FANS

72" Cyclone:

De-stratifies air on low speed covering 6000 square feet using only 300 watts of power!

ventec_005_yslm
picture_006

APPLICATIONS:

In industrial applications, our fan's air pattern covers over 6000 square feet of floor area and can be used on high ceilings up to 40'. Our fans positioned over shipping doors can create an air curtain to keep cold air out in the winter and hot air out in the Summer. Unlike traditional ceiling fans that slowly push air in a 360 degree radius, the 72" Cyclone can direct the air pattern where you need it the most. Run our fans on high speed to efficiently cool employees and machinery during hot conditions.

Ask us about agricultural buildings, greenhouses, processing plants, and stadium applications too!

FEATURES:

  1. Corrosion resistant fiberglass housing.
  2. Heavy duty pulley and bearing assembly
  3. Maintenance free motor
  4. Can be mounted on a steel post, column, or suspended from the ceiling
  5. Optional variable frequency drive
  6. 6 directional air flow deflectors
  7. Balanced 72" heavy duty corrosion resistant 6 paddle aluminum blade
  8. Shipped fully assembled (except air foil deflectors)
  9. Can reduce heating and cooling costs up to 50%
picture_008
post_mount

TECHNICAL SPECIFICATIONS:

  1. Weight: 375 lbs. fully assembled
  2. Motor is 3 HP or 2.2kw on high and .3kw on low 230/460 VAC
  3. Belt drive runs 300 RPM on high and 50 RPM on low.
  4. Throws air 100' on both sides for a total floor coverage of 200' x 35'
  5. Optional variable frequency drive
  6. Blade is 72" diameter 6 paddle
hvb36

High Volume HVB Basket Fan:

The new HVB series industrial / agricultural is designed to be the most powerful and efficient basket fans of its type in the market today. This fan is designed for the harshest environments, maximum performance and efficiency. use this fan where high performance air movement is a must.

APPLICATIONS:

  1. Animal cooling
  2. Individual cooling in warehouses, loading docks, and factories
  3. Circulates air in enclosed buildings and greenhouses
  4. Aids in insect control when air velocity reaches 300 FPM
  5. Moving air in shipping trucks and cargo containers when loading and unloading
  6. Creates a high velocity air curtain
  7. Cooling of machines and compressors
  8. Surface drying for wet floors and animal bedding
  9. Provides stress relief inside and out
  10.  Air de-stratification in buildings to reduce heating and cooling costs.

SPECIFICATIONS:

HVB12110C: 12" Diameter, DD, 1/10 HP, 115v, 1 amp, 1725 RPM, 2500 CFM, 22 lbs w/ 9' cord
HVB2013C: 20" Diameter, DD, 1/3 HP, 115v, 3.5 amps, 1725 RPM, 6400 CFM, 37 lbs. w/ 9' cord
HVB2412C: 24" Diameter, DD, 1/2 HP, 115v, 4.8 amps, 1725 RPM, 8800 CFM, 47 lbs. w/ 9' cord
HVB3612: 36" Diameter, DD, 1/2 HP, 115/230v, 6.0/3.0 amps, 825 RPM, 14000 CFM, 74 lbs.
HVB36123P: 36" Diameter, DD, 1/2 HP, 230/460v, 3.0/1.5 amps, 825 RPM, 14000 CFM, 74 lbs.

hvb361

18" Outdoor Fan

The HVW-18 series fan are ideal cooling and de-stratification in high humidity applications. This fan arrives completely assembled with a 3 speed pull chain 115v motor. Perfect for enclosed porches, horse barns, parking garages and much more!

SPECIFICATIONS:

HVW-18M: 18" Diameter, DD, 1/10 hp, 115v, 1.45 amps ( high), 1570 RPM, 6357 CFM. White color. UL listed
HVW-18MB: 18" diameter, DD, 1/10 hp, 15v, 1.45 amps ( high ), 1570 RPM, 6357 CFM, Black color. UL listed

658f3b75b1787e516776b0a9e60cd110
polfan_cu8g

High Velocity Poly Housing Fans:

The most powerful and efficient re-circulating fan available in the market today! Available in 24" and 36" sizes.

APPLICATIONS:

  1.  Exceptional air velocity is ideal for animal cooling in dairy or corrosion resistant environments like swine and poultry.
  2. People cooling in factories, warehouses and sporting events.
  3. Air de-stratification in buildings can reduce heating and cooling bills by up to 35%.
  4. Create a consistant air temperature in buildings and greenhouses.
  5. Used to change the air in shipping trucks and containers when loading or unloading.
  6. High velocity air pattern can develop an air curtain.
  7. Machine and compressor cooling.
  8. Surface drying for wet floors, golf greens and animal bedding.
  9. Heat stress relief inside and outside.

FEATURES:

1) Plastic corrosion resistant housing with built in UV protection.
2) Standard OSHA safety guards on the intake and exhaust.
3) Versatile wall and ceiling mount pivots 180 degrees with an adjustable mounting bracket that allows the head angle to be locked in place.
4) Motors are totally enclosed, high efficiency with sealed ball bearings.
5) Most powerful fans in the market today based on size and motor HP.
6) Well balanced and strong blade design for years of trouble free service.
7) Designed for optimal air throw and coverage.
8) Easy to clean and has no corners for dirt and disease build up.

SPECIFICATIONS:

24" FAN
24" diameter, direct drive, 1/2 HP, 115/230 volt, 7.4/4.8 amps, 9800 CFM, FPM @ 50': 525, FPM @ 100': 225

36" FAN
36" diameter, direct drive, 1/2 HP, 115/230 and 230/460 volt, 7.0 to 1.2 amps, 16000 CFM, FPM @ 50': 950, FPM @ 100': 525

polyfan1
haf2013

Legend OSHA High Volume HAF Basket Fan:

The new Legend Series OSHA High Volume HAF basket Fan is designed to create a high velocity air pattern at a low cost. the OSHA intake and exhaust guard can be mounted at any height. This fan is designed for the harshest horticultural, agricultural, and industrial environments. Has an optional 9' cord for "no electrician required" installation.

IDEAL APPLICATIONS:

  1. Exceptional air velocity is ideal for animal cooling in dairy or corrosion resistant environments like swine and poultry.
  2. People cooling in factories, warehouses and sporting venues.
  3. Air de-stratification in buildings can reduce heating and cooling costs by up to 35%.
  4. Creat a consistant air temperature in buildings or greeenhouses.
  5. Insect control when creating a velocity of 300 ft. per minute.
  6. Create an air exchange when placed in a wall.
  7. Used to change the air in shipping trucks and containers when loading or unloading.
  8. High velocity air pattern can develop an air curtain.
  9. Machine and compressor cooling.
  10. Surface drying for wet floors and animal bedding.
  11. Heat stress relief inside and outside.

FEATURES:

  1. Standard OSHA safety guards on intake and exhaust.
  2. Versatile wall and ceiling mount pivots 180 degrees and fan can turn 360 degrees.
  3. Motors are totally enclosed, high efficiency with sealed ball bearings.
  4. Most powerful basket fans in the market today based upon size and HP.
  5. Well balanced and strong blade design for years of trouble free service.
  6. Polyester powder coated guards for corrosion resistance.
  7. Designed for optimal air throw and coverage.
  8. Industry leading fan efficiency, up to 26 CFM / watt.
  9. Easy to clean.
  10. Some assembly required.

SPECIFICATIONS:

HAF2013:, 20" diameter, DD, 1/3 HP, 115/230v, 3.5/1.7 amps, 1725 RPM, 6200/2170 CFM, 350 FPM @ 50', 100 FPM @ 100'
HAF2013C: 20" diameter, DD, 1/3 HP, 115v, 3.5 amps, 1725 RPM, 6200/2170 CFM, 350 FPM @ 50', 100FPM @ 100 ' (with cord).
HAF2412: 24" diameter, DD, 1/2 HP, 115/230v, 4.8/2.4 amps, 1725 RPM, 8600/3010 CFM, 450 FPM @ 50', 150 FPM @ 100'
HAF2412C: 24" diameter, DD, 1/2 HP, 115v, 4.8 amps, 1725 RPM, 8600/3010 CFM, 450 FPM @ 50', 150 FPM @ 100' 9(with cord).
HAF3012: 30" diameter, DD, 1/2 HP, 115/230v, 6.0/3.0 amps, 850 RPM, 10200/3570 CFM, 450FPM @ 50', 150 fpm @ 100'
HAF3012C: 30" diameter, DD, 1/2 HP, 115v, 6.0 amps, 850 RPM, 10200/3570 CFM, 450 FPM @ 50', 150 FPM @ 100' (with cord).
